FS20: 20kg Integral Ice Cuber
27-117
Air cooled ice cuber
About the product
-
Available to finance with our award-winning interest-free credit and leasing
Learn more about our Drinks Service range
Take a look inside the G3
Specification
Technical
- Refrigerant
- R290
- Electrical supply
- 230/50/1
- Fuse rating (A)
- 10
- Current (A)
- 2.3
- Power (W)
- 653
- Refrigerant mass (g)
- 80
Dimensions
- Height (mm)
- 600
- Width (mm)
- 340
- Depth (mm)
- 480
- Net volume ( )
- 6.5
- Bin Capacity (kg)
- 6.5
- Leg type
- Feet
- Gross weight (kg)
- 33
- Net weight (kg)
- 29
Build
- Finish ext/int
- S/S & S/S
- System
- Integral
Energy
- Bin Capacity (kg)
- 6.5
- Climate Class
- 5
- AEC (kWh)
- 2135.25
- GWP
- 3
- Energy consumption (kWh/24hr)
- 5.85
Features and benefits
- Innovatively designed with new user-friendly electro-mechanical controls to ensure reliability
- The models also incorporate a condenser thermostat, which ensures a full harvest of cubes
- Produces ultra cold square cubes that last longer in the glass, ice bucket and the machine's storage bin
- Uses as little as 5 litres of water to produce 1 kilo of ice - important where water is metered.
- The new flush system ensures clear ice free from impurities and eliminates the risk of lime-scale
- Bin capacity: 6.5 kgs
- Ice: Cubed 35x37x32mm
Product downloads
Download all available product assets. Find user and service manuals here.
-
- A minimum clearance of 15cm (6") must be left at the sides of the machine for routing cooling air drawn into and exhausted out of the compartment to maintain a proper condensing operation
- Maximum ambient air temperature 40ºC; maximum input water temperature 35ºC
